Heavy Duty Industrial Floor Scale.

FM52e + XSB Series

User Selectable Parameters:


  • 5 x Filter Intensity Mode.
  • 3 x Backlight Mode.
  • 2 x Selectable Auto Tare Function.
  • 5 x RS232 Data Output Baud Rate.
  • 7 x Initial Zero Range.
  • 6 x Manual Zero Range.
  • 4 x Auto Zero Tracking Range.

  • 3 x Checkweighing Buzzer Output Mode.



Features:


  • 24 Bit Sigma to Delta (Σ-Δ) Analog-To-Digital Converter.

  • Multi Functions Indicator.

  • Free Capacity and Division Setting.

  • 6 x 1-Inch Numeric Digits.

  • Tracking Bar to Show Applied & Remaining Capacity.

  • Calibration Password Control.

  • Power Up To 4 X 350Ω Load Cells or 8 X 700Ω Load Cells.

  • Dual Power Source: - By Built-In Rechargeable Battery or External Power Adaptor.

  • Lower Power Consumption. Battery Operating Time = 200 Hours plus.

  • Built-in Real Time Clock.

  • Backlight, Built-In Rechargeable. Battery, External Power Adaptor, and Stainless Steel Wall/Desk Mount Holder Included.

XSB is designed & built to meet a wide range of heavy traffic & high-resolution industrial applications up to 6000kg. It delivers un-exceptional reliability, accuracy, and skin-smooth performance to meet weighing, batching, and counting needs.



Option:

  • Mild Steel Ramp.
  • Pit Installation Frame.



Order Code:

  • Model No.: - Nominal Capacity - Load Cell Type.


Examples:

  • XSB-1010-1T-A for platform size = 1 x 1m; nominal capacity = 500kg; with approved load cells.
  • XSB-1215-2T-N for platform size = 1.2 x 1.5m; nominal capacity = 2000kg; with FM Special Grade load cells.
